Bot Performance Analyzer

The Bot Performance Analyzer is designed to allow users to monitor and analyze a bots performance.

Bot Performance Analyzer Video

Bot Performance Analyzer UI

About

The Bot Performance Analyzer is a feature we integrated with the purpose of monitoring bot performance more easily. Sometimes you just have a lot of bots running and want to see how they are fairing with a little more detail than the bot dashboard shows. You can also run backtests from this page.

Charts Tab

Bot Chart Interval

Allows you to set the chart interval.

Secondary Chart Type

The default chart type will display a single market chart on the interval selected. Multi Indicator Chart will display a chart for one of the indicators you chose for this bots configuration. You may change the indicator displayed by click the chart icon on the Bot Tab under "Indicators".

Secondary Chart Interval

Allows you to select a differing time interval for the secondary chart.

Split View

Simply changes how the secondary chart will be displayed. Your options are either horizontally or vertically.

Load Price Charts

Unchecking this box will disable the charts on this page.

Show Volume

The default for this option is unchecked. Checking this box will display market volume data in your charts.

Show Revenue Chart

Toggling this option will either display or hide the bottom revenue chart.

Bot Tab

Bot Information

Display some basic information about the bot you have selected.

Safeties

This section will list the safeties you have configured for the selected bot. You can click the chart icon on the right to display the market chart for the desired safety.

Indicators

This section will list the indicators you have configured for the selected bot. You can click the chart icon on the right to display the market chart for the desired indicator.

Quick Backtest

The quick backtest buttons allow you to run quickly backtest your bot with some standard time frames.

Custom Backtest

Here you can set a custom start and end date to use for performing a custom backtest.

Revenue Tab

As the name implies, this section will display revenue information for the selected bot. You can change the metric (coin) used by selecting one of the buttons at the top of this tab.

Trades Tab

The trades tab will display information about the bots trading. Each section contains information that will help analyze the bots actions and keep track of some general information.
